METRO BANK - HAYES
SHORT PROJECT SPECIFICATION:
1: CURTAIN WALL TO BOTH SIDES OF GLASS CUBE:
GLASS:
Clear toughened double glazed units with a high performance coating.
FRAMING:
Full height 'Jansen VISS SG' toggle fixing.
INTERMEDIATE BAND:
Bright polished stainless steel pressing internally and externally.
External with slots for the 'Brise Soleil' to penetrate through.
GLASS:
Clear toughened double glazed units with a high performance coating.
FRAMING:
Full height 'Jansen VISS SG' toggle fixing.
INTERMEDIATE BAND:
Bright polished stainless steel pressing internally and externally.
External with slots for the 'Brise Soleil' to penetrate through.
2: GLASS CUBE:
GLASS:
Verticals – Toughened.
Roof - Toughened & Laminated glass.
METALWORK:
«ottom rail – mild steel angle forming channel and clad in bright polished stainless steel.
Bright polished stainless steel folded jambs channels and angles.
Polished stainless steel glazing brackets, splice bolts, purpose made st/st angles.
Mild steel splice plates and glass fin boxes, clad in bright polished stainless steel.
Bright polished stainless steel feature bands on both side of glass panels.
DOORS:
Extended door bottom rail, clad in bright polished stainless steel and 100 mm top rail. Bottom rails with manual locks. Floor springs. 'Abloy' electronic lock.
GLASS:
Verticals – Toughened.
Roof - Toughened & Laminated glass.
METALWORK:
«ottom rail – mild steel angle forming channel and clad in bright polished stainless steel.
Bright polished stainless steel folded jambs channels and angles.
Polished stainless steel glazing brackets, splice bolts, purpose made st/st angles.
Mild steel splice plates and glass fin boxes, clad in bright polished stainless steel.
Bright polished stainless steel feature bands on both side of glass panels.
DOORS:
Extended door bottom rail, clad in bright polished stainless steel and 100 mm top rail. Bottom rails with manual locks. Floor springs. 'Abloy' electronic lock.
